learning.Unrolled#

class bartorch.learning.Unrolled#

Bases: Module

Unrolled network: an iteration block applied a fixed number of times.

With every parameter frozen the stack reproduces the corresponding solver bit for bit; requires_grad_() on a step size, a penalty weight or a denoiser’s weights makes it trainable. One block shared by every iteration shares the weights; a sequence of blocks gives each iteration its own. MoDL is an ADMMBlock whose single term is an ImplicitPrior.

detach and checkpoint select the backward pass without changing the value computed:

by default the whole stack is recorded, and memory grows with the number of iterations;
detach=True starts each iteration from a detached state; with a loss on each image steps() yields, this is greedy per-iteration training, with memory independent of the number of iterations;
checkpoint=True keeps the states between iterations and recomputes each step in the backward pass, giving the end-to-end gradient at the cost of a second application of every block.

bartorch.optim.FixedPoint is the alternative without an iteration count, differentiated at the fixed point. Learned reconstruction compares the strategies.

Parameters:

block (nn.Module or sequence of nn.Module) – One of bartorch.optim’s iteration blocks, or one per iteration.
iterations (int, default=None) – Number of applications of a shared block; the sequence’s length for a sequence.
detach (bool, default=False) – Start each iteration from a detached state.
checkpoint (bool, default=False) – Recompute each iteration in the backward pass rather than store it.

Raises:

ValueError – A shared block without iterations, an empty sequence, an iterations that differs from the sequence’s length, or fewer than one iteration.

Notes

A checkpointed step is correct only if its recomputation reproduces it. PyTorch’s random state is restored for the recomputation, so dropout is reproduced; a BART term that draws random shifts from BART’s generator, such as Wavelet or LocallyLowRank with randshift=True, is not, and the gradient then does not belong to the forward pass. This is not checked.

Examples

>>> block = optim.ADMMBlock(priors.ImplicitPrior(denoiser), rho=0.05, cg_maxiter=10)
>>> block.rho.requires_grad_()
>>> model = learning.Unrolled(block, iterations=10, checkpoint=True)
>>> model(kspace, A).abs().sub(target).square().mean().backward()

block()#: The block applied at iteration k.

steps()#

Yield the image after each iteration.

Takes the arguments of forward(). A loss on each yielded image, with detach=True, is greedy per-iteration training.

forward()#

Run the iterations and return the last image.

Parameters:

y (torch.Tensor) – Data, with or without a leading batch axis.
A (LinearOperator) – Encoding operator, shared by every item of a batch.
x0 (torch.Tensor, default=None) – Starting image; zero when omitted, as in BART.

Returns:
